Machining Services

5 Axis CNC:Mazak Integrex 200-IIIS

With live tooling and fully integrated 5 axis CNC machining, combined with two 10” chucks to accommodate programmed hand-off for secondary operations on the back side of parts, this machine completes most of our more advanced component parts in a single setup.

Lathes:

CNC oil field style lathe: double chuck on headstock, large spindle bore – 6.93” (176 mm) through spindle bore; 27.95” (710 mm) diameter over bed; 18.9” (480 mm) over cross slide; 157.5” (4000 mm) between centers.

CNC lathe – 10”: Chuck Oil field style engine lathe double chuck on headstock, large spindle bore - 12 19/32” (320 mm) through spindle bore; 30” (760 mm) diameter over bed; 20 1/2” (520 mm) over cross slide; 118” (3000 mm) between centers.

Single chuck engine lathes: 4 1/16” (104 mm) through spindle bore; 34” (870 mm) diameter over bed; 25” (638 mm) over cross slide; 160” (4064 mm) between centers; 45 5/8” (1158 mm) gap bed

Milling Machines

CNC mill – X axis 118.11” (3000 mm); Y axis 31.5” (800 mm); Z axis 19.89” (505 mm)

CNC mill – X axis 39.37” (1000 mm); Y axis 20” (508 mm); Z axis 18.11” (460 mm)

(3) Conventional milling machines
